57mm Planetary Gear Motor with Brake 12V 15N.m 10.5rpm for Electric Retractable Tonneau Covers Truck Bed Covers
Product Details:
| Place of Origin: | China |
| Brand Name: | PM |
| Certification: | REACH & CE |
| Model Number: | PM57-PB12-1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20 Pieces |
|---|---|
| Price: | Negotiable |
| Packaging Details: | L42*W27*H23cm, strong export carton box outside,Poly foam inside |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 50000PCS per Month |
|
Detail Information |
|||
| Product Type: | Brush DC Gear Motor | Rated Speed: | 10.5RPM Or Customized |
|---|---|---|---|
| Rated Torque: | 15Nm Or Customized | Rated Voltage: | 12V To 48V DC Or Customized |
| Applicaiton Field: | Electric Retractable Tonneau Covers | Warranty: | 3 Years |
Product Description
57mm Planetary Gear Motor with Brake 12V 15N.m 10.5rpm for Electric Retractable Tonneau Covers Truck Bed Covers
Designed for Electric Retractable Tonneau Covers on trucks, this 57mm planetary gear motor integrates a mechanical brake, featuring low noise levels , high torque-bearing capacity, and exceptional durability.
This product represents a successful case developed for the Overseas automotive aftermarket.
Below are the key dimensions and technical data of the product:
Key Specifications for this Ø57mm dc brushed gear motor:
- Gearbox Outer Diameter: 57 mm
- Brush Motor Outer Diameter: 62mm
- Rated Voltage: 12V DC or customized
- Gearbox Length: 38.5mm or customized
- No load speed: 15 RPM.
- Rated Torque: 15Nm
- Rated Speed: 10.5 RPM
Remark:
- Please contact us for detailed specifications and drawings of the geared motor you need.
- We offer design and production services for customized geared motors (OEM & ODM).
To see the product catalogue on our Brushed DC Gear Motors Φ12-57 mm , please
Please review the dimensions of the gear motor below. Please note that we can provide deep customization
based on your size and data requirements.
